01. Ɔde ne nsa kyerɛɛ ne so
Adwumayɛ a ɛkorɔn, Tumi a ɛkorɔn, Ultra Wideband, Dede a ɛba fam 6-18GHz Tumi Amplifiers - Wɔ Stock mu, Dodow Kɛse a Ɛwɔ Hɔ
RF Nneɛma a Wɔde Yɛ Amplifiers nkyerɛmu
Yɛn High power RF amplifiers yɛ high-frequency power amplifiers foforo a etumi yɛ adwuma na ɛde nsɛnkyerɛnne kɔ bere tiaa bi mu. Wɔn nneɛma atitiriw no bi ne adwumayɛ a ɛkyɛn so te sɛ ahoɔhare kɛse a wɔde mena, latency a ɛba fam, adwumayɛ a ɛkɔ soro, frequency stability a ɛkyɛn so ne gain flatness, a ɛhwɛ hu sɛ nsɛnkyerɛnne no renkyinkyim wɔ amplification nhyehyɛe no mu.
Yɛn High power RF amplifiers no yɛ nea wɔde precision components na ɛyɛ de hwɛ hu sɛ anyinam ahoɔden adwumayɛ a ɛkorɔn na ɛyɛ den.
RF Nneɛma a Wɔde Yɛ Amplifiers Nnyinasosɛm
Sɛ wopɛ amplifiers indicators a wɔayɛ no sɛnea wopɛ pii a, yɛsrɛ wo, di yɛn ho nkɔmmɔ
| mpɛn dodow (Ghz) . | mfaso (db) . | P-1type | anyinam ahoɔden(v) . | tumi a wɔsɛe no( typ) . | ayera | nkitahodifo |
| 2-8 na ɛwɔ hɔ | ≥24 na ɛwɔ hɔ | ≥43 na ɛwɔ hɔ | +28 | 5.5A | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 2-18 na ɛwɔ hɔ | ≥20 na ɛwɔ hɔ | ≥40 na ɛwɔ hɔ | +28 | 3.5A type | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 2-6 na ɛwɔ hɔ | ≥20 na ɛwɔ hɔ | ≥43 na ɛwɔ hɔ | +28 | 3.2A typ a wde bhy mu | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 7-13 na ɛwɔ hɔ | ≥24 na ɛwɔ hɔ | ≥45 na ɛwɔ hɔ | +28 | 5A type | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 6-18 na ɛwɔ hɔ | ≥25 na ɛwɔ hɔ | ≥43 na ɛwɔ hɔ | +28 | 3.5A type | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 6-18 na ɛwɔ hɔ | ≥55 na ɛwɔ hɔ | ≥43 na ɛwɔ hɔ | +28 | 4.5A type | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 8-12 na ɛwɔ hɔ | ≥45 na ɛwɔ hɔ | ≥45.5 na ɛwɔ hɔ | +28 | 4.5A type | -60dbc type | SMA-50K na ɛwɔ hɔ |
| 13.5-15 na ɛwɔ hɔ | ≥20 na ɛwɔ hɔ | ≥40 na ɛwɔ hɔ | +28 | 3A type | -60dbc type | 0.38mm afiri a wɔde yɛ ade |
| 13.5-15 na ɛwɔ hɔ | ≥20 na ɛwɔ hɔ | ≥42.5 na ɛwɔ hɔ | +28 | 3A type | -60dbc type | 0.38mm afiri a wɔde yɛ ade |
| 13.5-15 na ɛwɔ hɔ | ≥20 na ɛwɔ hɔ | ≥43 na ɛwɔ hɔ | +28 | 3A type | -60dbc type | 0.38mm afiri a wɔde yɛ ade |
| 13.5-15 na ɛwɔ hɔ | ≥25 na ɛwɔ hɔ | ≥45 na ɛwɔ hɔ | +28 | 6A type | -60dbc type | 0.38mm afiri a wɔde yɛ ade |
| 13.5-15 na ɛwɔ hɔ | ≥25 na ɛwɔ hɔ | ≥45.5 na ɛwɔ hɔ | +28 | 6A type | -60dbc type | 0.38mm afiri a wɔde yɛ ade |
RF Amplifiers mfaso horow
High Speed Transmission a ɛwɔ Latency a ɛba fam
Wɔayɛ XST High Power RF amplifiers no sɛ ɛbɛma nsɛnkyerɛnne ayɛ kɛse na ɛde akɔma wɔ bere no fã ketewaa bi mu, na ɛbɛma data akɔ ntɛmntɛm. Afã a ɛmma wontumi ntra ase pii no ma wotumi de sɛnkyerɛnne no kɔ a ɛkame ayɛ sɛ ɛnyɛ nea ɛkyɛ, na ɛma wotumi de sɛnkyerɛnne no kɔ bere ankasa mu.
Frequency Stability a ɛda nsow ne Gain Flatness
XST High Power RF amplifiers no yɛ pɛpɛɛpɛ calibrated na tuned ma ɛhwɛ ma frequency stability a ɛkyɛn so na nya flatness wɔ adwumayɛ frequency band nyinaa so. Wei kyerɛ sɛ amplifier no ma mfasoɔ ne ahoɔden a ɛgyina pintinn a signal frequency nsakraeɛ mfa ho, ɛhwɛ sɛ signal no renkyinkyim wɔ amplification bere mu na ɛma system no nyinaa adwumayɛ tu mpɔn.
Pɛpɛɛpɛ Components ne Superior Quality
High Power RF afiri a ɛma nneɛma yɛ kɛsewɔde nneɛma a wɔde yɛ nneɛma a ɛkorɔn ne akwan a ɛkɔ akyiri a wɔfa so yɛ nneɛma na ɛyɛ na ama anyinam ahoɔden ayɛ adwuma yiye na akyɛ. Wɔhwehwɛ saa nneɛma yi mu denneennen na wɔsɔ hwɛ de hwɛ hu sɛ wodi dwumadie a ɛyɛ den paa no ho dwuma. Bere koro no ara mu no, ɔkwan a wɔfa so yɛ no pɛpɛɛpɛ no ma ahotoso ne nea egyina pintinn no yɛ kɛse na ɛtew huammɔdi dodow so.
Wide range of application anidaso ahorow
Esiane wɔn adwumayɛ ne wɔn su a ɛda nsow nti, wo High power RF amplifiers no de dwumadie ahodoɔ pii ma wɔ wireless communications, radar systems, imaging technology, medical devices ne nea ɛkeka ho. Sɛ́ ebia wɔde di dwuma de ma nsɛnkyerɛnne a wɔde mena no tumi yɛ kɛse anaasɛ wɔde ma data a wɔde mena no dodow ne ahotoso kɔ soro no, ɛde mfaso soronko ma.
Yɛrehwɛ kwan sɛ yɛne wo bedi nkitaho na yɛama woanya yɛn RF amplifiers no su ne adwumayɛ mu osuahu.
Sɛ́ ɛyɛ mfiridwuma ho afotu, nneɛma a wɔpaw, ɔsom a wɔahyɛ da ayɛ anaa mmoa a wɔde ma wɔ adetɔn akyi no, yɛbɛyɛ nea yebetumi biara de ano aduru a ɛyɛ adwumayɛfo ne nea etu mpɔn sen biara ama wo.
